Pipes
Our collection includes MS Pipes, ERW Pipes, and GI Pipes, each designed to cater to specific needs. Our products are manufactured with precision to deliver optimal flow, structural support, and resistance to environmental factors, making them suitable for multiple sectors.
A. MS Pipe
| Parameter | Specification |
|---|---|
| Size Range | 15 mm to 600 mm |
| Wall Thickness | 1.2 mm to 12 mm (light, medium, heavy) |
| Length | Standard 6 meters / custom up to 12 m |
| End Finish | Plain End, Beveled, or Threaded |
| Surface Finish | Black (mill finish), Painted, or Coated |
| Coating Options | Red oxide primer, black bitumen, galvanization |
B. ERW Pipe
ERW (Electric Resistance Welded) Pipes are manufactured by cold-forming a flat steel strip into a cylindrical shape and then welding the seam longitudinally using high-frequency electric resistance. These pipes are known for their uniform wall thickness, smooth surface finish, and strong mechanical properties. ERW pipes are widely used in structural applications, industrial systems, fencing, and general engineering purposes.
| Parameter | Specification |
|---|---|
| Outer Diameter | ½” to 16” (15 mm – 406 mm) |
| Wall Thickness | 1.2 mm to 12 mm |
| Length | Standard 6 m / Custom up to 12 m |
| Material Grade | IS 1161, IS 1239, IS 3589, ASTM A53 / A500 |
| Surface Finish | Black, Red Oxide Coated, Galvanized |
| End Type | Plain End / Beveled / Threaded |
| Tolerance | As per IS/ASTM standards |
C. GI Pipe
GI Pipes, or Galvanized Iron Pipes, are steel pipes that are coated with a protective layer of zinc through a process known as hot-dip galvanization. This zinc coating acts as a corrosion-resistant barrier, making GI Pipes highly suitable for outdoor, water, and plumbing applications where exposure to moisture and weathering is a concern. These pipes are widely used in residential, commercial, and industrial infrastructure for fluid transport and structural use.
| Parameter | Specification |
|---|---|
| Size Range | 15 mm to 150 mm nominal bore |
| Wall Thickness | Light, Medium & Heavy (As per IS 1239) |
| Length | Standard 6 meters / Custom on request |
| Coating | Hot-dip Zinc Coated (40–300 GSM) |
| End Type | Plain End / Threaded & Coupled (T&C) |
| Standard | IS 1239 (Part 1), BS 1387, ASTM A53 |
| Surface Finish | Shiny Silver (Hot-Dip Galvanized) |
Frequently Asked Questions
Which type of pipe is best for outdoor use?
Are MS Pipes suitable for water supply?
Do all these pipes come in different sizes and thicknesses?
Ask ChatGPT
| Parameter | Specification |
|---|---|
| Base Metal Thickness | 0.42 mm/ 0.45 mm |
| Depth | 24 mm |
| Overall width | 992 mm |
| Steel | ZINCALUME® steel, COLORBOND® XRW steel *Standard offering includes COLORBOND® XRW steel but other options like COLORBOND Ultra steel, COLORBOND® XPD steel and COLORBOND® Metallic steel can also be used after consultation from Tata BlueScope Steel authorities |
| Steel Grade | G550 (550 MPa yield strength) |
| Total Coated Thickness | 0.47 mm/ 0.50 mm |
| Effective cover width | 935 mm |
| Min. Roof Slope | 3 degree |
| Coating Class (min.) | ZINCALUME AZ150 (150g/m2) (55% Aluminium, 43.5% Zinc, 1.5% Si) as per AS1397 / IS15961 – with Super Durable Polyester COLORBOND® steel XRW quality paint system of approved color conforming to AS/NZS 2728 type-4 / IS15965 class 3 |
| Application | Roofing, Wall cladding |
